| Nambari ya Sehemu | A030VAC01.1 |
| Chapa | AUO |
| Ukubwa | 3.0 |
| Maombi | Digital Still Camera |
| Azimio | 720×480 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6S1P |
| Kiolesura | Serial |
| mtengenezaji | AUO |
| jina la mfano | A030VAC01.1 |
| ukubwa wa skrini | 3.0 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 720(RGB)×480 287PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 63.72 × 42.48 (H×V) |
| muhtasari(mm) | 78 × 51.1 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Hard coating (6H) |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| majibu | 18/18 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | - |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 16.7M 70% NTSC |
| backlight | 6S1P WLED , No Driver |
| wingi | 27.0g (Typ.) |
| kutumika kwa | Digital Still Camera Digital Video Camera |
| kiwango cha upya | - |
| skrini ya kugusa | Without |
| aina ya ishara | Serial RGB (8-bit) + SPI , 51 pins FPC |
| usambazaji wa voltage | 1.8/3.0V (Typ.)(VDDIO/VDD) |
| max. ukadiriaji | Storage Temp.: -25 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
