| Nambari ya Sehemu | A035VL01 V3 |
| Chapa | AUO |
| Ukubwa | 3.5 |
| Maombi | DVC |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 315 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | AUO |
| mfano wa paneli | A035VL01 V3 |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 75.6×45.36 mm |
| muhtasari | 86.1×51.66 mm |
| uso | Glare (Haze 0%) |
| mwangaza | 315 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit) |
| wakati wa majibu | 15/30 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| voltage ya pembejeo | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| maombi | DVC |
