| Nambari ya Sehemu | A065VL01 V1 |
| Chapa | AUO |
| Ukubwa | 6.5 |
| Maombi | MP4 |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | AUO |
| mfano wa paneli | A065VL01 V1 |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 6.5 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 143.4×79.2 mm |
| muhtasari | 157.2×89.2 mm |
| uso | Antiglare (Haze 25%) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 12/18 (Typ.)(Tr/Td) |
| angle ya kutazama | 55/55/45/60 (Min.)(CR≥10)(L/R/U/D) |
| aina ya taa | 4S1PWLEDWithout Driver |
| kiolesura cha ishara | TTL (1 ch, 6-bit), 80 pins |
| voltage ya pembejeo | 3.3/10.5/13.5/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| maombi | MP4 |
