| Nambari ya Sehemu | AA121TH01-DE1 |
| Chapa | Mitsubishi |
| Ukubwa | 12.1 |
| Maombi | IA |
| Azimio | 1280×800 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 1000:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | Mitsubishi |
| mfano wa paneli | AA121TH01-DE1 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 12.1 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 261.12×163.2 mm |
| muhtasari | 303×205.1×16.3 mm |
| uso | Clear, Hard coating (5H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 12/12 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
| AA121TD01 | Mitsubishi | 12.1 | 1280×800 |
| AA121TD01-DE3 | Mitsubishi | 12.1 | 1280×800 |
| AA121TD02 | Mitsubishi | 12.1 | 1280×800 |
| AA121TH01-DE1 | Mitsubishi | 12.1 | 1280×800 |
| AA121TH11-DE1 | Mitsubishi | 12.1 | 1280×800 |
| G121XN01 V0 | AUO | 12.1 | 1024×768 |
| LMG9980ZWCC-01 | KOE | 12.1 | 800×600 |
| LQ121S1LG84 | SHARP | 12.1 | 800×600 |
| LTN121W1-L03 | Samsung | 12.1 | 1280×800 |
| N121I6-L01 | Innolux | 12.1 | 1280×800 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| G150XGE-L04 Rev.C4 | Innolux | 15.0 | 1024×768 |
| HGS128641-Y-EH-LV | Other | 2.7 | 128×64 |
| KCS6448HSTT-X3 | Kyocera | 10.4 | 640×480 |
| LTD104C11Z | TOSHIBA | 10.4 | 640×480 |
| LTM10C209A | TOSHIBA | 10.4 | 640×480 |
| M190EN01 V1 | AUO | 19.0 | 1280×1024 |
| M606-L24A | NAN YA | 5.7 | 320×240 |
| PM070WL1 | E Ink | 7.0 | 800×480 |
| TCG035QVLPDANN-GN50 | Kyocera | 3.5 | 320×240 |
