| Nambari ya Sehemu | ACX565AKM-7 |
| Chapa | SONY |
| Ukubwa | 3.5 |
| Maombi | MPH |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 275 |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | CDP |
| chapa ya paneli | SONY |
| mfano wa paneli | ACX565AKM-7 |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | VSPEC II, Normally Black, Transflective |
| eneo la kazi | 76.8×46.08 mm |
| muhtasari | 87.9×52.18 mm |
| uso | |
| mwangaza | 275 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.)(Transmissive)24:1 (Typ.)(Reflective) |
| kuonyesha rangi | 16.7M (8-bit), CIE193170% |
| wakati wa majibu | 12/7 (Typ.)(Tr/Td) |
| angle ya kutazama | |
| masafa | 60Hz |
| aina ya taa | 3S2PWLEDWithout Driver |
| kiolesura cha ishara | CDP (2 Lane) + SPI, 24 pins |
| voltage ya pembejeo | 1.8/2.75V (Typ.)(VDDI/VDD) |
| maombi | MPH |
