| Nambari ya Sehemu | AM-1024768FCTMQW-T00H |
| Chapa | AMPIRE |
| Ukubwa | 10.4 |
| Maombi | Industrial |
| Azimio | 1024×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 262K/16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AMPIRE |
| mfano | AM-1024768FCTMQW-T00H |
| ukubwa wa diagonal | 10.4 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×768 [XGA] 123PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 210.4(H)×157.8(V) mm |
| muhtasari dim. | 238.6(H)×175.8(V) mm |
| mwangaza | 280 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1200:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 14/11 (Typ.)(Tr/Td) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10) |
| hali ya uendeshaji | Normally Black, Transmissive |
| rangi ya msaada | 262K/16.2M 57% NTSC |
| chanzo cha mwanga | WLED , 30K hours , With LED Driver |
| uzito | - |
| iliyoundwa kwa ajili ya | Industrial |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | PCAP |
| aina ya kiolesura | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
