| Nambari ya Sehemu | AM-1024768TTMQW-T00H |
| Chapa | AMPIRE |
| Ukubwa | 10.4 |
| Maombi | Industrial |
| Azimio | 1024×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AMPIRE |
| mfano | AM-1024768TTMQW-T00H |
| ukubwa wa diagonal | 10.4 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×768 [XGA] 123PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 211.2(H)×158.4(V) mm |
| muhtasari dim. | 236(H)×176.9(V) ×7.9(D) mm |
| eneo la bezel | 214.8(H)×162.0(V) mm |
| matibabu | Antiglare |
| mwangaza | 280 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| tazama mwelekeo | 6 o'clock |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| angle ya kutazama | 75/75/75/75 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 262K/16.7M |
| chanzo cha mwanga | WLED [4 strings] , 30K hours , With LED Driver |
| uzito | 290g (Max.) |
| iliyoundwa kwa ajili ya | Industrial |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | 4-wire Resistive Touch |
| aina ya kiolesura | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| G104SN05 V0 | AUO | 10.4 | 800×600 |
| LM-CJ53-22NAK | SANYO | 10.4 | 640×480 |
| LQ10D341 | SHARP | 10.4 | 640×480 |
| LQ10D368 | SHARP | 10.4 | 640×480 |
| LQ10D41 | SHARP | 10.4 | 640×480 |
| LTM104V3-100 | Samsung | 10.4 | 640×480 |
| PD104SL7 | E Ink | 10.4 | 800×600 |
