| Nambari ya Sehemu | AM-1024768Y2TZQW-A1H |
| Chapa | AMPIRE |
| Ukubwa | 10.4 |
| Maombi | Industrial Outdoor H |
| Azimio | 1024×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AMPIRE |
| mfano wa paneli | AM-1024768Y2TZQW-A1H |
| saizi ya paneli | 10.4" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1024(RGB)×768, XGA, 123PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 211.2(W)×158.4(H) mm |
| ufunguzi wa bezel | 213.2(W)×160.4(H) mm |
| saizi ya muhtasari | 236(W)×174.3(H) ×10.4(D) mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| kuonyesha rangi | 16.2M |
| aina ya taa | WLED , 30K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | TBD |
| maombi | Industrial Outdoor High Brightness |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
