| Nambari ya Sehemu | AM-19201200CTZQW-02 |
| Chapa | AMPIRE |
| Ukubwa | 10.1 |
| Maombi | Industrial Outdoor H |
| Azimio | 1920×1200 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AMPIRE |
| mfano | AM-19201200CTZQW-02 |
| ukubwa wa diagonal | 10.1 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1920(RGB)×1200 [WUXGA] 225PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 216.576(H)×135.36(V) mm |
| muhtasari dim. | 244.8(H)×155.3(V) ×7.07(D) mm |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | AHVA, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 49% NTSC |
| chanzo cha mwanga | WLED , 50K hours , With LED Driver |
| uzito | - |
| iliyoundwa kwa ajili ya | Industrial Outdoor High Brightness |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (2 ch, 8-bit) , 45 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| HSD100IFW1-A02 | HannStar | 10.1 | 1024×600 |
| HSD101PFW1-B00 | HannStar | 10.1 | 1024×576 |
| HSD101PFW3-A00 | HannStar | 10.1 | 1024×600 |
| LP101WSB-TLN1 | LG Display | 10.1 | 1024×600 |
| LTL101DL03-T01 | Samsung | 10.1 | 2560×1600 |
| N101BCG-GK1 | Innolux | 10.1 | 1366×768 |
| Q101IRE-GB1 | Innolux | 10.1 | 1280×800 |
