| Nambari ya Sehemu | AM-320240LQTZQW-50H |
| Chapa | AMPIRE |
| Ukubwa | 3.5 |
| Maombi | Industrial Outdoor H |
| Azimio | 320×240 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6S2P |
| Kiolesura | Parallel |
| chapa ya paneli | AMPIRE |
| saizi ya paneli | 3.5" |
| azimio | 320(RGB)×240, QVGA, 115PPI |
| eneo la maonyesho | 70.08(W)×52.56(H) mm |
| saizi ya muhtasari | 76.9(W)×63.9(H) ×3.45(D) mm |
| mwangaza | 800 cd/m² (Typ.) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kuonyesha rangi | 16.7M 60% NTSC |
| masafa | 60Hz |
| uzito wa paneli | - |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit) + SPI , 50 pins FPC |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| mfano wa paneli | AM-320240LQTZQW-50H |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 72.88(W)×54.94(H) mm |
| uso | - |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| hali ya kuonyesha | Normally Black, Transmissive |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| aina ya taa | 6S2P WLED , 36K hours , Without Driver |
| skrini ya kugusa | Without |
| maombi | Industrial Outdoor High Brightness Instruments & Meters |
