| Nambari ya Sehemu | AM-480272HBTMQW-T00H |
| Chapa | AMPIRE |
| Ukubwa | 4.3 |
| Maombi | Industrial |
| Azimio | 480×272 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 250:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 7S1P |
| Kiolesura | Parallel |
| mtengenezaji | AMPIRE |
| jina la mfano | AM-480272HBTMQW-T00H |
| ukubwa wa skrini | 4.3 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 480(RGB)×272 (WQVGA) 128PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 95.04 × 53.856 (H×V) |
| muhtasari(mm) | 105.5 × 67.2 × 7.99 (H×V×D) |
| eneo la bezel(mm) | 98.7 × 57.5 (H×V) |
| matibabu | - |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 250 : 1 (Typ.) (TM) |
| angle ya kutazama | 65/65/45/45 (Typ.)(CR≥10) |
| majibu | 40 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | 6 o'clock |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 16.7M |
| backlight | 7S1P WLED , 20K hours , No Driver |
| wingi | - |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | PCAP |
| aina ya ishara | Parallel RGB (1 ch, 8-bit) , FPC 54 pins |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
