| Nambari ya Sehemu | AM-640480G2TNQW-T08H |
| Chapa | AMPIRE |
| Ukubwa | 5.7 |
| Maombi | Industrial |
| Azimio | 640×480 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 250:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| mtengenezaji | AMPIRE |
| jina la mfano | AM-640480G2TNQW-T08H |
| ukubwa wa skrini | 5.7 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 640(RGB)×480 (VGA) 141PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 115.2 × 86.4 (H×V) |
| muhtasari(mm) | 127 × 98.43 × 10.2 (H×V×D) |
| eneo la bezel(mm) | 118.0 × 89.2 (H×V) |
| matibabu | - |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 250 : 1 (Typ.) (TM) |
| angle ya kutazama | 70/70/50/50 (Typ.)(CR≥10) |
| majibu | 50 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | 12 o'clock |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 262K 50% NTSC |
| backlight | WLED , 20K hours , With LED Driver |
| wingi | - |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | 4-wire Resistive Touch |
| aina ya ishara | Parallel RGB (1 ch, 6-bit) , Connector 40 pins |
| usambazaji wa voltage | 3.3/5.0V (Typ.)(VCC/VDD) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
