| Nambari ya Sehemu | AM-640480V2TZQW-TA7H |
| Chapa | AMPIRE |
| Ukubwa | 5.7 |
| Maombi | Industrial Outdoor H |
| Azimio | 640×480 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 262K |
| Mwangaza nyuma | 4S7P |
| Kiolesura | LVDS |
| chapa ya paneli | AMPIRE |
| mfano wa paneli | AM-640480V2TZQW-TA7H |
| saizi ya paneli | 5.7" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 640(RGB)×480, VGA, 141PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 115.2(W)×86.4(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 127(W)×98.43(H) ×10.88(D) mm |
| uso | - |
| mwangaza | 850 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1200:1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| kuonyesha rangi | 262K 60% NTSC |
| aina ya taa | 4S7P WLED , 50K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | PCAP |
| uzito wa paneli | - |
| maombi | Industrial Outdoor High Brightness |
| kiolesura cha ishara | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| EL320.240.36 AG | Lumineq | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G00 | Kyocera | 5.7 | 320×240 |
| LQ057Q3DG02 | SHARP | 5.7 | 320×240 |
| LTA057A347F | TOSHIBA | 5.7 | 320×240 |
| MST-G320240DBSW-213W-E | Other | 5.7 | 320×240 |
| PD057VU4 | E Ink | 5.7 | 320×240 |
| TM057QDHG04 | Tianma | 5.7 | 640×480 |
