| Nambari ya Sehemu | AM-800480LATMQW-TN0H |
| Chapa | AMPIRE |
| Ukubwa | 5.0 |
| Maombi | IA |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 360 |
| CR | 250:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | AMPIRE |
| mfano wa paneli | AM-800480LATMQW-TN0H |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 5.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 108×64.8 mm |
| muhtasari | 118.5×74×5.16 mm |
| uso | |
| mwangaza | 360 cd/m² (Typ.) |
| uwiano wa utofautishaji | 250:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193152% |
| wakati wa majibu | 15/35 (Max.)(Tr/Td) |
| angle ya kutazama | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S6PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit), 45 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
