| Nambari ya Sehemu | AM-800600K2TMQW-04H |
| Chapa | AMPIRE |
| Ukubwa | 10.4 |
| Maombi | Industrial |
| Azimio | 800×600 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AMPIRE |
| saizi ya paneli | 10.4" |
| azimio | 800(RGB)×600, SVGA, 96PPI |
| eneo la maonyesho | 211.2(W)×158.4(H) mm |
| saizi ya muhtasari | 243(W)×185.6(H) mm |
| mwangaza | 500 cd/m² (Typ.) |
| angle ya kutazama | 70/70/50/60 (Typ.)(CR≥10) |
| mwonekano bora zaidi | 6 o'clock |
| kuonyesha rangi | 262K 50% NTSC |
| masafa | 60Hz |
| uzito wa paneli | - |
| kiolesura cha ishara | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -35 ~ 85 °C |
| mfano wa paneli | AM-800600K2TMQW-04H |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 214.8(W)×162.7(H) mm |
| uso | - |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| wakati wa majibu | 5/15 (Typ.)(Tr/Td) |
| aina ya taa | WLED , 30K hours , With LED Driver |
| skrini ya kugusa | Without |
| maombi | Industrial |
