| Nambari ya Sehemu | AM-800600MGTMQW-00H |
| Chapa | AMPIRE |
| Ukubwa | 8.4 |
| Maombi | Industrial |
| Azimio | 800×600 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 600:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 12S4P |
| Kiolesura | LVDS |
| mtengenezaji | AMPIRE |
| jina la mfano | AM-800600MGTMQW-00H |
| ukubwa wa skrini | 8.4 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×600 (SVGA) 119PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 170.4 × 127.8 (H×V) |
| muhtasari(mm) | 203 × 145.5 × 10.9 (H×V×D) |
| eneo la bezel(mm) | 174.15 × 131.2 (H×V) |
| matibabu | - |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 600 : 1 (Typ.) (TM) |
| angle ya kutazama | 75/75/60/70 (Typ.)(CR≥10) |
| majibu | 8 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | - |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 16.7M |
| backlight | 12S4P WLED , 50K hours , With LED Driver |
| wingi | TBD |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 8-bit) , Connector 20 pins |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
