| Nambari ya Sehemu | AM-800600MGTMQW-02H |
| Chapa | AMPIRE |
| Ukubwa | 8.4 |
| Maombi | Industrial |
| Azimio | 800×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 600:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 12S4P |
| Kiolesura | LVDS |
| chapa ya paneli | AMPIRE |
| mfano wa paneli | AM-800600MGTMQW-02H |
| saizi ya paneli | 8.4" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 800(RGB)×600, SVGA, 119PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 170.4(W)×127.8(H) mm |
| ufunguzi wa bezel | 174.15(W)×131.2(H) mm |
| saizi ya muhtasari | 203(W)×145.5(H) ×11.7(D) mm |
| uso | - |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 600:1 (Typ.) (TM) |
| angle ya kutazama | 75/75/60/70 (Typ.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | - |
| wakati wa majibu | 8 (Typ.)(Tr+Td) |
| kuonyesha rangi | 16.7M |
| aina ya taa | 12S4P WLED , 50K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | TBD |
| maombi | Industrial |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
