| Nambari ya Sehemu | AMSA05BV09 |
| Chapa | SAMSUNG |
| Ukubwa | 10.5 |
| Maombi | Pad & Tablet |
| Azimio | 2560×1600 |
| Muundo | AM-OLED, OLED |
| Mwangaza | |
| CR | 54000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | self |
| Kiolesura | MIPI |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | AMSA05BV09 |
| saizi ya paneli | 10.5" |
| aina ya paneli | AM-OLED, OLED |
| azimio | 2560(RGB)×1600, 287PPI |
| muundo wa pixel | S-Stripe RGB |
| eneo la maonyesho | 226.56(W)×141.6(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 251.4(W)×171.1(H) mm |
| uso | - |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 54000:1 (Min.) (TM) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥200) |
| hali ya kuonyesha | - |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | - |
| kuonyesha rangi | 16.7M 100% NTSC |
| aina ya taa | self |
| masafa | 60Hz |
| skrini ya kugusa | PCAP |
| dereva ic | COG Built-in EA8002ASA |
| uzito wa paneli | 143/148g (Typ./Max.) |
| maombi | Pad & Tablet |
| kiolesura cha ishara | MIPI (2 ch, 4 data lanes) , 80 pins Connector |
| voltage ya pembejeo | 1.8/3.3/3.8V (Typ.)(VDD1/VDD3/VBAT) |
| mazingira | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
