| Nambari ya Sehemu | AT101WSM-N11-58P0 |
| Chapa | BOE |
| Ukubwa | 10.1 |
| Maombi | Automotive Display |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | BOE |
| mfano | AT101WSM-N11-58P0 |
| ukubwa wa diagonal | 10.1 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×600 [WSVGA] 117PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 222.72(H)×125.28(V) mm |
| muhtasari dim. | 235(H)×144.9(V) ×5.44(D) mm |
| eneo la bezel | 226(H)×128.6(V) mm |
| matibabu | Antiglare, Hard coating (3H) |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| tazama mwelekeo | - |
| wakati wa majibu | 25 (Typ.)(Tr+Tf) |
| angle ya kutazama | 80/80/60/70 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 262K/16.7M 50% NTSC |
| chanzo cha mwanga | WLED [3S14P] , 20K hours , W/O Driver |
| uzito | 300g (Max.) |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| usambazaji wa nguvu | 3.3/11/21/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| B101AW01 V2 HW0A | AUO | 10.1 | 1024×576 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| LP101WS1-TLB3 | LG Display | 10.1 | 1024×576 |
| N101L6-L0D | Innolux | 10.1 | 1024×600 |
| P101KDA-AP1 | Innolux | 10.1 | 1200×1920 |
| PQ 3Qi-01 | Pixel Qi | 10.1 | 1024×600 |
| YX101GL-01A | SEBO | 10.1 | 1280×800 |
