| Nambari ya Sehemu | AT102TN42 |
| Chapa | Innolux |
| Ukubwa | 10.2 |
| Maombi | NOPC |
| Azimio | 1024×600 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 500:1 |
| Rangi | 262K/16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | INNOLUX |
| mfano wa paneli | AT102TN42 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.2 inch |
| azimio | 1024(RGB)×600 , WSVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 221.798×131.52 mm |
| muhtasari | 235×145.8×5.45 mm |
| uso | Clear |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K/16.2M (6-bit / 6-bit + Dithering) |
| wakati wa majibu | 10/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/70/80 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| rohs: | |
| maombi | NOPC |
| AT102TN42 | Innolux | 10.2 | 1024×600 |
| B101AW01 V0 HW5A | AUO | 10.1 | 1024×576 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| HSD070PFW1-A00 | HannStar | 7.0 | 1024×600 |
| HT101WSB-100 | BOE | 10.1 | 1024×600 |
| LTN101NT02-L01 | Samsung | 10.1 | 1024×600 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| LTN101NT07-W01 | Samsung | 10.1 | 1024×600 |
| N089A1-L01 | Innolux | 8.9 | 1280×768 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
