| Nambari ya Sehemu | B121EW01 V1 |
| Chapa | AUO |
| Ukubwa | 12.1 |
| Maombi | NBPC |
| Azimio | 1280×800 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | AU Optronics |
| mfano wa paneli | B121EW01 V1 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 12.1 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 261.12×163.2 mm |
| muhtasari | 275.8×178×5.5 mm |
| mtindo wa sura | Wedge (PCBA Bent, Depth ≥5.2mm) |
| uso | |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Min.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 10/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 40/40/20/40 (Min.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NBPC |
| B121EW01 V1 | AUO | 12.1 | 1280×800 |
| B121EW03 V0 | AUO | 12.1 | 1280×800 |
| B121EW03 V3 | AUO | 12.1 | 1280×800 |
| B121EW03 V8 | AUO | 12.1 | 1280×800 |
| B121EW07 V1 | AUO | 12.1 | 1280×800 |
| B121EW09 V2 | AUO | 12.1 | 1280×800 |
| B121EW09 V3 HW0A | AUO | 12.1 | 1280×800 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| B121EW10 V0 | AUO | 12.1 | 1280×800 |
| B121EW10 V1 | AUO | 12.1 | 1280×800 |
| B156HW03 V0 | AUO | 15.6 | 1920×1080 |
| B156XTN02.2 | AUO | 15.6 | 1366×768 |
| B160HW02 V0 | AUO | 16.0 | 1920×1080 |
| BT140GW03 V.2 | Innolux | 14.0 | 1366×768 |
| HSD150PX16-A | HannStar | 15.0 | 1024×768 |
| LP140WH1-TLC6 | LG Display | 14.0 | 1366×768 |
| LTN140AT07-T01 | Samsung | 14.0 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| N133I6-L01 | Innolux | 13.3 | 1280×800 |
| N140BGE-LB2 | Innolux | 14.0 | 1366×768 |
