AUO B140XTN03.3 HW0A hifadhidata, vipimo, hisa, programu www.looklcd-mk.com
LookLCD LookLCD


B140XTN03.3 HW0A

B140XTN03.3 HW0A
B140XTN03.3 HW0A
B140XTN03.3 HW0A thumb B140XTN03.3 HW0A thumb
Chapa
AUO
Ukubwa
14.0
Maombi
NBPC
Azimio
1366×768
Muundo
LCM
Mwangaza
200
CR
400:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
eDP
In Stock
3734
Vipimo

Nambari ya Sehemu B140XTN03.3 HW0A
ChapaAUO
Ukubwa14.0
MaombiNBPC
Azimio1366×768
MuundoLCM
Mwangaza200
CR400:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraeDP
chapa ya paneliAUO
mfano wa paneliB140XTN03.3 HW0A
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli14.0 inch
azimio1366(RGB)×768 , WXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi309.399×173.952 mm
muhtasari320.4×205.1×3.2 mm
mtindo wa suraSlim (PCBA Flat, Depth ≤3.2mm)
usoAntiglare, Hard coating (3H)
mwangaza200 cd/m² (Typ.)
uwiano wa utofautishaji400:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193145%
wakati wa majibu8 (Typ.)(Tr+Td)
angle ya kutazama45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taaWLEDEmbedded (LED Driver)
kiolesura cha isharaeDP (1 Lane), 30 pins
voltage ya pembejeo3.3V (Typ.)
maombiNBPC
Mfano wa Familia
B140XTN01.3 AUO 14.0 1366×768
B140XTN02.0 AUO 14.0 1366×768
B140XTN02.3 AUO 14.0 1366×768
B140XTN02.4 AUO 14.0 1366×768
B140XTN03.1 AUO 14.0 1366×768
B140XTN03.2 AUO 14.0 1366×768
B140XTN03.3 HW0A AUO 14.0 1366×768
B140XTN03.4 AUO 14.0 1366×768
B140XTN03.5 AUO 14.0 1366×768
B140XTN03.9 AUO 14.0 1366×768
