B141PW04 V1 HW0A

B141PW04 V1 HW0A
B141PW04 V1 HW0A
B141PW04 V1 HW0A thumb B141PW04 V1 HW0A thumb
Chapa
AUO
Ukubwa
14.1
Maombi
NBPC
Azimio
1440×900
Muundo
LCM
Mwangaza
300
CR
400:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
eDP
In Stock
28
Vipimo

Nambari ya Sehemu B141PW04 V1 HW0A
ChapaAUO
Ukubwa14.1
MaombiNBPC
Azimio1440×900
MuundoLCM
Mwangaza300
CR400:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraeDP
chapa ya paneliAUO
mfano wa paneliB141PW04 V1 HW0A
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli14.1 inch
azimio1440(RGB)×900 , WXGA+
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi303.48×189.675 mm
muhtasari319.5×206.5×5.5 mm
mtindo wa suraWedge (PCBA Bent, Depth ≥5.2mm)
usoAntiglare (Haze 11%), Hard coating (3H)
mwangaza300 cd/m² (Typ.)
uwiano wa utofautishaji400:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193145%
wakati wa majibu8 (Typ.)(Tr+Td)
angle ya kutazama40/40/15/30 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taaWLEDEmbedded (LED Driver)
kiolesura cha isharaeDP (2 Lanes), 30 pins
voltage ya pembejeo3.3V (Typ.)
maombiNBPC
Mfano wa Familia
B141PW04 V0 HW0A AUO 14.1 1440×900
B141PW04 V0 HW1A AUO 14.1 1440×900
B141PW04 V0 HW2A AUO 14.1 1440×900
B141PW04 V1 HW0A AUO 14.1 1440×900
LP141WX1-TLA1 LG Display 14.1 1280×800
LP141WX3-TLN4 LG Display 14.1 1280×800
LP141WX5-TLD1 LG Display 14.1 1280×800
LP141X2 LG Display 14.1 1024×768
LTN141AT12-J01 Samsung 14.1 1280×800
N141I3-L01 Innolux 14.1 1280×800
