| Nambari ya Sehemu | B156HW01 V7 |
| Chapa | AUO |
| Ukubwa | 15.6 |
| Maombi | NBPC |
| Azimio | 1920×1080 |
| Muundo | LCM |
| Mwangaza | 270 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | B156HW01 V7 20 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 15.6 inch |
| azimio | 1920(RGB)×1080 , FHD |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 344.16×193.59 mm |
| muhtasari | 359.3×209.5×5.7 mm |
| mtindo wa sura | Wedge (PCBA Bent, Depth ≥5.2mm) |
| uso | Glare (Haze 0%), Hard coating (3H), Reflection 5.0% (Max.) |
| mwangaza | 270 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193195% |
| wakati wa majibu | 8 (Typ.)(Tr+Td); |
| angle ya kutazama | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (2 ch, 6-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NBPC |
