| Nambari ya Sehemu | B156XTN08.0 |
| Chapa | AUO |
| Ukubwa | 15.6 |
| Maombi | Laptop |
| Azimio | 1366×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | eDP |
| chapa ya paneli | AUO |
| mfano wa paneli | B156XTN08.0 (AUO20EC) |
| saizi ya paneli | 15.6" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1366(RGB)×768, WXGA, 100PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 344.232(W)×193.536(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 350.66(W)×216.15(H) ×3.2(D) mm |
| uso | Glare (Haze 0%) |
| mwangaza | 220 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| angle ya kutazama | 45/45/15/35 (Min.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | 6 o'clock |
| wakati wa majibu | 8 (Typ.)(Tr+Td) |
| kuonyesha rangi | 262K 45% NTSC |
| aina ya taa | WLED , 15K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | - |
| mtindo wa sura | Slim (PCBA Flat, T≤3.2mm) |
| maombi | Laptop |
| kiolesura cha ishara | eDP (1 Lane) , eDP1.2 , 40 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
