| Nambari ya Sehemu | B156XTT01.2 |
| Chapa | AUO |
| Ukubwa | 15.6 |
| Maombi | Laptop |
| Azimio | 1366×768 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| mtengenezaji | AUO |
| ukubwa wa skrini | 15.6 inch |
| nambari ya pixel | 1366(RGB)×768 (WXGA) 100PPI |
| eneo amilifu(mm) | 344.232 × 193.536 (H×V) |
| eneo la bezel(mm) | - |
| mwangaza | 200 cd/m² (Typ.) |
| angle ya kutazama | 45/45/15/35 (Typ.)(CR≥10) |
| mtazamo mzuri | 6 o'clock |
| kina cha rangi | 262K 45% NTSC |
| umbo la muhtasari | Slim (PCBA Flat, T≤3.2mm) |
| kiwango cha upya | 60Hz |
| aina ya ishara | LVDS (1 ch, 6-bit) , 40 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| jina la mfano | B156XTT01.2 (AUO12EC) |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 364.9 × 224.56 × 5.2 (H×V×D) |
| matibabu | Glare (Haze 0%), Hard coating (7H) |
| uwiano wa utofautishaji | 500 : 1 (Typ.) (TM) |
| majibu | 8 (Typ.)(G to G) ms |
| hali ya kazi | TN, Normally White, Transmissive |
| backlight | WLED , 15K hours , With LED Driver |
| kutumika kwa | Laptop |
| skrini ya kugusa | PCAP, Optical Bonding |
