| Nambari ya Sehemu | B170PW03 V4 |
| Chapa | AUO |
| Ukubwa | 17.0 |
| Maombi | NBPC |
| Azimio | 1440×900 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | B170PW03 V4 3 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 17.0 inch |
| azimio | 1440(RGB)×900 , WXGA+ |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 367.2×229.5 mm |
| muhtasari | 382.2×244.5×6.8 mm |
| mtindo wa sura | Wedge (PCBA Bent, Depth ≥5.2mm) |
| uso | Glare (Haze 0%) |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 12/4 (Typ.)(Tr/Td) |
| angle ya kutazama | 45/45/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 6-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NBPC |
| B170PW01 V1 | AUO | 17.0 | 1440×900 |
| B170PW02 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V1 | AUO | 17.0 | 1440×900 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| B170PW03 V4 | AUO | 17.0 | 1440×900 |
| B170PW03 V5 | AUO | 17.0 | 1440×900 |
| B170PW06 V2 | AUO | 17.0 | 1440×900 |
| B170PW06 V3 | AUO | 17.0 | 1440×900 |
| B170PW07 V0 | AUO | 17.0 | 1440×900 |
| B156HAT01.0 | AUO | 15.6 | 1920×1080 |
| B156XW03 V1 | AUO | 15.6 | 1366×768 |
| HT14P12-101 | HYDIS | 14.1 | 1400×1050 |
| LP140WH4-TLB1 | LG Display | 14.0 | 1366×768 |
| LP154WU1-A1K3 | LG Display | 15.4 | 1920×1200 |
| LTD121EWVB | TOSHIBA | 12.1 | 1280×800 |
| LTN154P3-L05 | Samsung | 15.4 | 1680×1050 |
| N133HSE-EA3 | Innolux | 13.3 | 1920×1080 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
| UB141X01 | UNIPAC | 14.1 | 1024×768 |
