| Nambari ya Sehemu | BP096WX1-100 |
| Chapa | BOE |
| Ukubwa | 9.6 |
| Maombi | PAD |
| Azimio | 800×1280 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | BOE |
| mfano wa paneli | BP096WX1-100 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.6 inch |
| azimio | 800(RGB)×1280 , WXGA |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| eneo la kazi | 129×206.4 mm |
| muhtasari | 136.8×217.1×4.2 mm |
| uso | Antiglare (Haze 3.1%) |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193150% |
| wakati wa majibu | 20/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 7S4PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 45 pins |
| voltage ya pembejeo | 1.8/3.7V (Typ.)(VDD/VDDI) |
| maombi | PAD |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HJ080IA-01B | Innolux | 8.0 | 1024×768 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| LD083WU1-SPA3 | LG Display | 8.3 | 1200×1920 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
