BT140GW01 V.5

BT140GW01 V.5
BT140GW01 V.5
BT140GW01 V.5 thumb BT140GW01 V.5 thumb
Chapa
Innolux
Ukubwa
14.0
Maombi
NBPC
Azimio
1366×768
Muundo
LCM
Mwangaza
200
CR
600:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
LVDS
In Stock
1542
Vipimo

Nambari ya Sehemu BT140GW01 V.5
ChapaInnolux
Ukubwa14.0
MaombiNBPC
Azimio1366×768
MuundoLCM
Mwangaza200
CR600:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraLVDS
chapa ya paneliCHIMEI INNOLUX
mfano wa paneliBT140GW01 V.5 4 Compatible model
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli14.0 inch
azimio1366(RGB)×768 , WXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi309.399×173.952 mm
muhtasari323.5×192×5.2 mm
mtindo wa suraWedge (PCBA Bent, Depth ≥5.2mm)
usoGlare (Haze 0%), Hard coating (3H)
mwangaza200 cd/m² (Typ.)
uwiano wa utofautishaji600:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193145%
wakati wa majibu8 (Typ.)(Tr+Td)
angle ya kutazama40/40/15/30 (Min.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taaWLEDEmbedded (LED Driver)
kiolesura cha isharaLVDS (1 ch, 6-bit), 40 pins
voltage ya pembejeo3.3V (Typ.)
maombiNBPC
Mfano wa Familia
B140XTN03.1 AUO 14.0 1366×768
BT140GW01 V.0 Innolux 14.0 1366×768
BT140GW01 V.4 Innolux 14.0 1366×768
BT140GW01 V.5 Innolux 14.0 1366×768
BT140GW01 V.A Innolux 14.0 1366×768
BT140GW02 V.0 Innolux 14.0 1366×768
BT140GW02 V.2 Innolux 14.0 1366×768
BT140GW02 V.9 Innolux 14.0 1366×768
BT140GW03 V.2 Innolux 14.0 1366×768
LP140WF1-SPB1 LG Display 14.0 1920×1080
