| Nambari ya Sehemu | C042FAN01.8 |
| Chapa | AUO |
| Ukubwa | 4.2 |
| Maombi | Outdoor High Brightn |
| Azimio | 480×272 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 262K |
| Mwangaza nyuma | 3S2P |
| Kiolesura | |
| mtengenezaji | AUO |
| jina la mfano | C042FAN01.8 |
| ukubwa wa skrini | 4.2 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 480(RGB)×272 (WQVGA) 131PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 92.88 × 52.632 (H×V) |
| muhtasari(mm) | 102.8 × 68.52 × 20 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare |
| mwangaza | 700 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Min.)(CR≥10) |
| majibu | 13/14 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | AHVA, Normally Black, Transmissive |
| kina cha rangi | 262K 71% NTSC |
| backlight | 3S2P WLED , 10K hours , No Driver |
| wingi | 89.8g (Typ.) |
| kutumika kwa | Outdoor High Brightness Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| HVA42WV1-M00 | HYDIS | 4.2 | 480×800 |
| LQ042B5DG02 | SHARP | 4.2 | 400×96 |
| LQ042T5DZ01 | SHARP | 4.2 | 480×272 |
| LQ042T5DZ01A | SHARP | 4.2 | 480×272 |
| LQ042T5DZ11 | SHARP | 4.2 | 480×272 |
| LT042MDV5000 | JDI | 4.2 | 768×1280 |
