| Nambari ya Sehemu | C070VW03 V0 |
| Chapa | AUO |
| Ukubwa | 7.0 |
| Maombi | CNS |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | AUO |
| mfano wa paneli | C070VW03 V0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 157.2×82.8 mm |
| muhtasari | 167×92.9×5.75 mm |
| uso | Antiglare (Haze 25%) |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 6/10 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 50 pins |
| voltage ya pembejeo | 3.3/9.9/15/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| maombi | CNS |
