| Nambari ya Sehemu | CLAA156WA12 |
| Chapa | CPT |
| Ukubwa | 15.6 |
| Maombi | NBPC |
| Azimio | 1366×768 |
| Muundo | LCM |
| Mwangaza | 220 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | eDP |
| chapa ya paneli | CPT |
| mfano wa paneli | CLAA156WA12 3 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 15.6 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 344.232×193.536 mm |
| muhtasari | 359.3×209.5×5.5 mm |
| mtindo wa sura | Wedge (PCBA Bent, Depth ≥5.2mm) |
| uso | Antiglare |
| mwangaza | 220 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193160% |
| wakati wa majibu | 3/5 (Typ.)(Tr/Td) |
| angle ya kutazama | 45/45/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | eDP (1 Lane), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NBPC |
