| Nambari ya Sehemu | DV212FBB-N10 |
| Chapa | BOE |
| Ukubwa | 21.2 |
| Maombi | Digital Signage Stre |
| Azimio | 1920×360 |
| Muundo | a-Si TFT-LCD, CELL |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| mfano wa paneli | DV212FBB-N10 |
| saizi ya paneli | 21.2" |
| aina ya paneli | a-Si TFT-LCD, CELL |
| azimio | 1920(RGB)×360, 92PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 529.416(W)×99.265(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 537.216(W)×109.6(H) mm |
| uso | Antiglare (Haze 25%) |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 1200:1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya kuonyesha | HADS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 8 (Typ.)(G to G) |
| kioo kina | - |
| uhamishaji | 4.8% (Typ.)(with Polarizer) |
| kuonyesha rangi | 16.7M 72% NTSC |
| aina ya taa | No B/L |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| dereva ic | COF Built-in 6 source + 1 gate chips |
| uzito wa paneli | 200g (Typ.) |
| maombi | Digital Signage Stretched Bar LCD |
| kiolesura cha ishara | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltage ya pembejeo | 12.0V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
