Lumineq EL320.240.36 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com
LookLCD LookLCD


EL320.240.36

EL320.240.36
EL320.240.36
EL320.240.36 thumb EL320.240.36 thumb
Chapa
Lumineq
Ukubwa
5.7
Maombi
IA
Azimio
320×240
Muundo
EL
Mwangaza
50
CR
50:1
Rangi
Mono(Yellow)
Mwangaza nyuma
self
Kiolesura
Parallel Data
In Stock
24
Vipimo

Nambari ya Sehemu EL320.240.36
ChapaLumineq
Ukubwa5.7
MaombiIA
Azimio320×240
MuundoEL
Mwangaza50
CR50:1
RangiMono(Yellow)
Mwangaza nyumaself
KiolesuraParallel Data
chapa ya paneliLumineq
mfano wa paneliEL320.240.36
aina ya paneli EL , EL
saizi ya paneli5.7 inch
azimio320×240 , QVGA
eneo la kazi115.1×86.3 mm
muhtasari148.1×104.7 mm
uso
mwangaza50 cd/m² (Typ.)
uwiano wa utofautishaji50 : 1 (Typ.)
kuonyesha rangiMono(Yellow) (1-bit)
angle ya kutazama89/89/89/89 (Typ.)(L/R/U/D)
masafa120Hz
kiolesura cha isharaParallel Data (1ch, 4-bit), 20 pins
voltage ya pembejeo5/12V (Typ.)(VL/VH)
maombiIA
Mfano wa Familia
EL320.240.36 AGL Lumineq 5.7 320×240
EL320.240.36 ET Lumineq 5.7 320×240
EL320.240.36 ET CC Lumineq 5.7 320×240
EL320.240.36 HB Lumineq 5.7 320×240
EL320.240.36 HB NE PLANAR 5.7 320×240
EL320.240.36 HB SE PLANAR 5.7 320×240
EL320.240.36 IN Lumineq 5.7 320×240
EL320.240.36 LK Lumineq 5.7 320×240
EL320.256-FD6 Lumineq 4.8 320×256
EL320.256-FD7 Lumineq 4.8 320×256
