| Nambari ya Sehemu | EV121WXM-N12 |
| Chapa | BOE |
| Ukubwa | 12.1 |
| Maombi | Medical Imaging |
| Azimio | 1280×800 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | BOE |
| mfano | EV121WXM-N12 |
| ukubwa wa diagonal | 12.1 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1280(RGB)×800 [WXGA] 124PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 261.12(H)×163.2(V) mm |
| muhtasari dim. | 277.7(H)×180.6(V) ×9.2(D) mm |
| eneo la bezel | 264.12(H)×166.2(V) mm |
| matibabu | Antiglare (Haze 25%) |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1200:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | ADS, Normally Black, Transmissive |
| rangi ya msaada | 262K/16.7M 100% sRGB |
| chanzo cha mwanga | WLED [12S4P] , 50K hours , With LED Driver |
| uzito | TBD |
| iliyoundwa kwa ajili ya | Medical Imaging |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA121SP01 | Mitsubishi | 12.1 | 800×600 |
| AA121TD01-DE3 | Mitsubishi | 12.1 | 1280×800 |
| B121EW07 V1 | AUO | 12.1 | 1280×800 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| FLC31SVC6S-17 | Fujitsu | 12.1 | 800×600 |
| LQ121S1DG42 | SHARP | 12.1 | 800×600 |
| LQ121S1LG45 | SHARP | 12.1 | 800×600 |
| LTD121KM1K | TOSHIBA | 12.1 | 1400×1050 |
| LTM12C318S | TOSHIBA | 12.1 | 1024×768 |
