| Nambari ya Sehemu | EV190E0M-N50 |
| Chapa | BOE |
| Ukubwa | 19.0 |
| Maombi | Medical Imaging |
| Azimio | 1280×1024 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | Grayscale |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| mfano wa paneli | EV190E0M-N50 |
| saizi ya paneli | 19.0" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1280(LCR)×1024, SXGA, 86PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 374.784(W)×299.827(H) mm |
| ufunguzi wa bezel | 378.8(W)×303(H) mm |
| saizi ya muhtasari | 396(W)×324(H) ×10.4(D) mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 1300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1200:1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 14 (Typ.)(G to G) |
| kuonyesha rangi | Grayscale |
| aina ya taa | WLED , 50K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 1.69Kgs (Typ.) |
| maombi | Medical Imaging |
| kiolesura cha ishara | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltage ya pembejeo | 5.0V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| G190EG02 V0 | AUO | 19.0 | 1280×1024 |
| G190ETN02.0 | AUO | 19.0 | 1280×1024 |
| HSD190MEN3-A03 | HannStar | 19.0 | 1280×1024 |
| LM190E09-TLD1 | LG Display | 19.0 | 1280×1024 |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| M190EG02 V9 | AUO | 19.0 | 1280×1024 |
| M190PP01 V0 | AUO | 19.0 | 1440×900 |
| MT190AW01 V.C | Innolux | 19.0 | 1440×900 |
| NA19020-C961 | Fujitsu | 19.0 | 1280×1024 |
| TMS190WX1-05TB | Tianma | 19.0 | 1440×900 |
