| Nambari ya Sehemu | G070VAN01.0 |
| Chapa | AUO |
| Ukubwa | 7.0 |
| Maombi | Industrial |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1300:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AUO |
| mfano | G070VAN01.0 |
| ukubwa wa diagonal | 7.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 800×480(RGB) [WVGA] 133PPI |
| usanidi | RGB Horizontal Stripe |
| eneo la kazi | 152.4(H)×91.44(V) mm |
| muhtasari dim. | 166.6(H)×107(V) ×10(D) mm |
| eneo la bezel | 154.2(H)×93.24(V) mm |
| matibabu | Antiglare |
| mwangaza | 480 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1300:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 11/19 (Max.)(Tr/Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya uendeshaji | AHVA, Normally Black, Transmissive |
| rangi ya msaada | 262K/16.7M 70% NTSC |
| chanzo cha mwanga | WLED [7S2P] , 50K hours , W/O Driver |
| uzito | 175±10%g |
| iliyoundwa kwa ajili ya | Industrial |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
