| Nambari ya Sehemu | G101EAN02.2 |
| Chapa | AUO |
| Ukubwa | 10.1 |
| Maombi | Industrial |
| Azimio | 1280×800 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | G101EAN02.2 |
| saizi ya paneli | 10.1" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1280(RGB)×800, WXGA, 149PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 216.96(W)×135.6(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 227.91(W)×148(H) ×7.75(D) mm |
| uso | Hard coating |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 29 (Typ.)(Tr+Td) |
| kuonyesha rangi | 16.7M 50% NTSC |
| aina ya taa | WLED , 50K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 290g (Max.) |
| maombi | Industrial |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) , 40 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
