| Nambari ya Sehemu | G170ETN03.1 |
| Chapa | AUO |
| Ukubwa | 17.0 |
| Maombi | Industrial |
| Azimio | 1280×1024 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AUO |
| mfano | G170ETN03.1 |
| ukubwa wa diagonal | 17.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1280(RGB)×1024 [SXGA] 96PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 337.92(H)×270.336(V) mm |
| muhtasari dim. | 358.5(H)×296.5(V) ×10.8(D) mm |
| eneo la bezel | 341.7(H)×274.1(V) mm |
| matibabu | Antiglare, Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | - |
| wakati wa majibu | 3.8/1.2 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 16.7M 72% NTSC |
| chanzo cha mwanga | WLED [9S4P] , 30K hours , W/O Driver |
| uzito | 1.27Kgs (Typ.) |
| iliyoundwa kwa ajili ya | Industrial |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (2 ch, 8-bit) , 30 pins Connector |
| usambazaji wa nguvu | 5.0V (Typ.) |
| mazingira | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| CLAA170EA07Q | CPT | 17.0 | 1280×1024 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTA170D200F | TOSHIBA | 17.0 | 1280×1024 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-L01 | Samsung | 17.0 | 1920×1200 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
