| Nambari ya Sehemu | G190EAN01.3 |
| Chapa | AUO |
| Ukubwa | 19.0 |
| Maombi | Industrial Medical I |
| Azimio | 1280×1024 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| mtengenezaji | AUO |
| jina la mfano | G190EAN01.3 |
| ukubwa wa skrini | 19.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1280(RGB)×1024 (SXGA) 86PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 376.32 × 301.056 (H×V) |
| muhtasari(mm) | 396 × 324 × 15.8 (H×V×D) |
| eneo la bezel(mm) | 380.32 × 305.06 (H×V) |
| matibabu | Antiglare |
| mwangaza | 330 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| majibu | 13/12 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | AHVA, Normally Black, Transmissive |
| kina cha rangi | 16.7M 72% NTSC |
| backlight | WLED , 50K hours , With LED Driver |
| wingi | 1.70±0.15Kgs |
| kutumika kwa | Industrial Medical Imaging |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (2 ch, 8-bit) , Connector 30 pins |
| usambazaji wa voltage | 5.0V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| G190EAN01.0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V1 | AUO | 19.0 | 1280×1024 |
| G190EG01 V2 | AUO | 19.0 | 1280×1024 |
| G190EG02 V0 | AUO | 19.0 | 1280×1024 |
| G190EG02 V1 | AUO | 19.0 | 1280×1024 |
| G190ETN01.0 | AUO | 19.0 | 1280×1024 |
| G190ETN01.2 | AUO | 19.0 | 1280×1024 |
| G190ETN01.4 | AUO | 19.0 | 1280×1024 |
| G190ETN02.0 | AUO | 19.0 | 1280×1024 |
