| Nambari ya Sehemu | GV122WXM-N80 |
| Chapa | BOE |
| Ukubwa | 12.2 |
| Maombi | Industrial |
| Azimio | 1280×800 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| mtengenezaji | BOE |
| jina la mfano | GV122WXM-N80 |
| ukubwa wa skrini | 12.2 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1280(RGB)×800 (WXGA) 123PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 262.656 × 164.16 (H×V) |
| muhtasari(mm) | 278 × 184 × 9.91 (H×V×D) |
| eneo la bezel(mm) | 264.66 × 166.66 (H×V) |
| matibabu | - |
| mwangaza | 450 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 30 (Typ.)(Tr+Td); 45 (Typ.)(G to G) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | ADS, Normally Black, Transmissive |
| kina cha rangi | 16.7M 50% NTSC |
| backlight | WLED , With LED Driver |
| wingi | 564g (Typ.) |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 8-bit) , 30 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
