| Nambari ya Sehemu | H220VA01 |
| Chapa | AUO |
| Ukubwa | 2.2 |
| Maombi | Mobile Phone |
| Azimio | 240×320 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 75:19:1 |
| Rangi | 262K |
| Mwangaza nyuma | 4S1P |
| Kiolesura | Parallel |
| mtengenezaji | AUO |
| ukubwa wa skrini | 2.2 inch |
| nambari ya pixel | 240(RGB)×320 (QVGA) 180PPI |
| eneo amilifu(mm) | 33.84 × 45.12 (H×V) |
| eneo la bezel(mm) | 35.4 × 46.92 (H×V) |
| mwangaza | 100 cd/m² (Typ.) |
| angle ya kutazama | 47/28/30/80 (Typ.)(CR≥10) |
| mtazamo mzuri | 6 o'clock |
| kina cha rangi | 262K 42% NTSC |
| wingi | - |
| kiwango cha upya | - |
| aina ya ishara | Parallel RGB (1 ch, 6-bit) + SPI , 39 pins FPC |
| usambazaji wa voltage | 2.8V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| jina la mfano | H220VA01 |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 40.6 × 56.66 × 3.11 (H×V×D) |
| matibabu | - |
| uwiano wa utofautishaji | 75 : 1 (Typ.) (TM) 9:1 (Typ.) (RF) |
| majibu | 29 (Typ.)(Tr+Td) ms |
| hali ya kazi | TN, Normally White, Transflective |
| backlight | 4S1P WLED , No Driver |
| kutumika kwa | Mobile Phone |
| skrini ya kugusa | Without |
