| Nambari ya Sehemu | H245QBN02.0 |
| Chapa | AUO |
| Ukubwa | 2.5 |
| Maombi | MP3 |
| Azimio | 240×432 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 150:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | AUO |
| mfano wa paneli | H245QBN02.0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 2.5 inch |
| azimio | 240(RGB)×432 |
| hali ya kuonyesha | ECB, Normally White, Transmissive |
| eneo la kazi | 30.24×54.432 mm |
| muhtasari | 34.44×60.68 mm |
| uso | |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 150:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 10/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | MIPI (1 data lane), 12 pins |
| voltage ya pembejeo | 1.8/3.0V (Typ.)(VDD3/VCI) |
| maombi | MP3 |
