| Nambari ya Sehemu | H345VW01 V0 |
| Chapa | AUO |
| Ukubwa | 3.5 |
| Maombi | MPH |
| Azimio | 480×800 |
| Muundo | LCM |
| Mwangaza | 320 |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | AUO |
| mfano wa paneli | H345VW01 V0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 480(RGB)×800 , WVGA |
| hali ya kuonyesha | VA, Normally Black, Transmissive |
| eneo la kazi | 45.072×75.12 mm |
| muhtasari | 49.02×83.52 mm |
| uso | |
| mwangaza | 320 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Min.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193170% |
| wakati wa majibu | 50/50 (Max.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1S6PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (2 data lanes), 24 pins |
| voltage ya pembejeo | 1.8/2.8V (Typ.)(VDDI/VDD) |
| maombi | MPH |
