AUO H546DLB01.1 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com

H546DLB01.1


Chapa
AUO
Ukubwa
5.5
Maombi
MPH
Azimio
1080×1920
Muundo
OLED
Mwangaza
350
CR
10000:1
Rangi
16.7M
Mwangaza nyuma
self
Kiolesura
MIPI
In Stock
15500
Vipimo

Nambari ya Sehemu H546DLB01.1
ChapaAUO
Ukubwa5.5
MaombiMPH
Azimio1080×1920
MuundoOLED
Mwangaza350
CR10000:1
Rangi16.7M
Mwangaza nyumaself
KiolesuraMIPI
chapa ya paneliAUO
mfano wa paneliH546DLB01.1
aina ya paneli AM-OLED , OLED
saizi ya paneli5.5 inch
azimio1080(RGB)×1920 , FHD
eneo la kazi68.04×120.96 mm
muhtasari70.84×128.01 mm
usoHard coating (3H)
mwangaza350 cd/m² (Typ.)
uwiano wa utofautishaji10000 : 1 (Min.)
kuonyesha rangi16.7M (8-bit), CIE1931103%
angle ya kutazama80/80/80/80 (Min.)(CR≥1600)(L/R/U/D)
dereva icCOG Built-in RM69070
kiolesura cha isharaMIPI (2 data lanes), 40 pins
voltage ya pembejeo1.8/3.0/4.6/7.6V (Typ.)(IOVCC/VCI/OVDD/AVDD)
maombiMPH
