| Nambari ya Sehemu | HJ070IA-02F |
| Chapa | Innolux |
| Ukubwa | 7.0 |
| Maombi | UMPC |
| Azimio | 1280×800 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | CHIMEI INNOLUX |
| mfano wa paneli | HJ070IA-02F |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 149.76×93.6 mm |
| muhtasari | 161.2×107.2×4.5 mm |
| uso | Hard coating |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193150% |
| wakati wa majibu | 15/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 40 pins |
| voltage ya pembejeo | 3.3/9.74/22.7/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| maombi | UMPC |
| CLAA070NC0DCW | CPT | 7.0 | 1024×600 |
| CLAA070NP01 | CPT | 7.0 | 1024×600 |
| HJ070IA-02F | Innolux | 7.0 | 1280×800 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| LD070WS2-SL01 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL04 | LG Display | 7.0 | 1024×600 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| LTL070AL01-L01 | Samsung | 7.0 | 1280×800 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
