| Nambari ya Sehemu | HM200WD1-100 |
| Chapa | BOE |
| Ukubwa | 20.0 |
| Maombi | DMPC |
| Azimio | 1600×900 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| mfano wa paneli | HM200WD1-100 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 20.0 inch |
| azimio | 1600(RGB)×900 , HD+ |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 442.8×249.075 mm |
| muhtasari | 462.8×272 mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC) |
| wakati wa majibu | 1.5/3.5 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 13S4PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
