| Nambari ya Sehemu | HSD061IDW1-A00-R00 |
| Chapa | HannStar |
| Ukubwa | 6.1 |
| Maombi | Automotive Display |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | 6S2P |
| Kiolesura | Parallel |
| chapa ya paneli | HannStar |
| mfano wa paneli | HSD061IDW1-A00-R00 |
| saizi ya paneli | 6.1" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 800(RGB)×480, WVGA, 153PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 132(W)×79.2(H) mm |
| ufunguzi wa bezel | 143.3(W)×81.6(H) mm |
| saizi ya muhtasari | 144.8(W)×87.6(H) ×4.8(D) mm |
| uso | Antiglare (Haze 8%), Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| angle ya kutazama | 75/75/60/70 (Typ.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | - |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| kuonyesha rangi | 262K 48% NTSC |
| aina ya taa | 6S2P WLED , 10K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | 4-wire Resistive Touch |
| uzito wa paneli | 140g (Max.) |
| maombi | Automotive Display |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit) + SPI , 50 pins FPC |
| voltage ya pembejeo | 1.8/3.3/3.3V (Typ.)(VDD1/VDD2/VCI) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| A061FW01 V0 | AUO | 6.1 | 480×234 |
| A061VW01 V0 | AUO | 6.1 | 800×480 |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| GCX142AKM-E | SONY | 6.1 | 800×480 |
| K6488L-FF | CITIZEN | 6.1 | 640×480 |
| LA061WQ1-TD04 | LG Display | 6.1 | 480×272 |
| LQ061Y1VG01 | SHARP | 6.1 | 800×480 |
| PM061WX1 | E Ink | 6.1 | 800×480 |
