| Nambari ya Sehemu | HSD070PFW5-A00 |
| Chapa | HannStar |
| Ukubwa | 7.0 |
| Maombi | Pad & Tablet |
| Azimio | 1024×600 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 3S7P |
| Kiolesura | MIPI |
| mtengenezaji | HannStar |
| jina la mfano | HSD070PFW5-A00 |
| ukubwa wa skrini | 7.0 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1024(RGB)×600 (WSVGA) 169PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 153.6 × 90 (H×V) |
| muhtasari(mm) | 161.16 × 100.97 × 5.04 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Hard coating |
| mwangaza | 550 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 13/15 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS Pro, Normally Black, Transmissive |
| kina cha rangi | 16.7M 50% NTSC |
| backlight | 3S7P WLED , 10K hours , With LED Driver |
| wingi | 75.0/85.0g (Typ./Max.) |
| kutumika kwa | Pad & Tablet |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | MIPI (4 data lanes) , 40 pins Connector |
| usambazaji wa voltage | 1.8/3.3/10.7/17/-10V (Typ.)(VDD1/VDD2/AVDD/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -20 ~ 65 °C Operating Temp.: -10 ~ 60 °C |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| HSD070PFW1-A00 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-D00 | HannStar | 7.0 | 1024×600 |
| HSD070PWW1-B01 | HannStar | 7.0 | 1280×800 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| LB070WV1-TD07 | LG Display | 7.0 | 800×480 |
| LQ070Y5DA02A | SHARP | 7.0 | 800×480 |
