| Nambari ya Sehemu | HSD090IHW1-A11 |
| Chapa | HannStar |
| Ukubwa | 9.0 |
| Maombi | Automotive Display |
| Azimio | 1280×720 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa ya paneli | HannStar |
| saizi ya paneli | 9.0" |
| azimio | 1280(RGB)×720, WXGA, 163PPI |
| eneo la maonyesho | 198.912(W)×111.888(H) mm |
| saizi ya muhtasari | 210.7(W)×124.1(H) mm |
| mwangaza | 600 cd/m² (Typ.) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kuonyesha rangi | 16.7M 70% NTSC |
| masafa | 60Hz |
| uzito | - |
| mfano wa paneli | HSD090IHW1-A11 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | - |
| uso | Antireflection |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| hali ya kuonyesha | IPS Pro, Normally Black, Transmissive |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| aina ya taa | WLED |
| skrini ya kugusa | Without |
| maombi | Automotive Display |
